Processor
Supports 2nd and 3rd Gen AMD Ryzen™ / Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics Desktop Processors for Socket AM4
Chipset
AMD® X570 Chipset
Memory
- 4 DDR4 memory slots, support up to 128GB (depending on the processor)
- 3rd Gen AMD Ryzen™ Processors support DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 Mhz by JEDEC, and 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400 Mhz by A-XMP OC MODE
- 2nd Gen AMD Ryzen™ Processors, 1st and 2nd Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors support DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 Mhz by JEDEC, and 2667 /2800 / 2933 /3000 /3066 /3200 /3466 Mhz by A-XMP OC MODE
- Dual channel memory architecture
- Supports non-ECC UDIMM memory
- ports ECC UDIMM memory (non-ECC mode)
- Supports un-buffered memory
Slots
- 1 x PCIe 4.0/ 3.0 x16 slot (PCI_E1)
- 3rd Gen AMD Ryzen™ support PCIe 4.0 x16 mode
- 2nd Gen AMD Ryzen™ support PCIe 3.0 x16 mode
- Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics support PCIe 3.0 x8 mode
- 1 x PCIe 4.0/ 3.0 x16 slot (PCI_E3, supports x4 mode)
- 3 x PCIe 3.0 x1 slots
Onboard Graphics
- 1 x HDMI 1.4 port, supports a maximum resolution of 4096×2160 @24Hz
Multi-GPU
- Supports 2-Way AMD® CrossFire™ Technology
Storage
AMD® X570 Chipset
- 4x SATA 6Gb/s ports(SATA3-SATA6)
- 2 x M.2 slot (Key M)
-
- M2_1 slot (from AMD® Processor)
- Supports PCIe 4.0 x4 (3rd Gen AMD Ryzen™)
- Supports PCIe 3.0 x4 (2nd Gen AMD Ryzen™/ Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics)
- Supports 2242/ 2260/ 2280/ 22110 storage devices
- M2_2 slot (from AMD® X570 Chipset)
- Supports PCIe 3.0 x4 and SATA 6Gb/s
- Supports 2242/ 2260/ 2280 storage devices
- M2_1 slot (from AMD® Processor)
ASMedia ASM1061
-
- 2x SATA 6Gb/s ports (SATA5, SATA6)
-
RAID
AMD® X570 Chipset
- Supports RAID 0, RAID 1 and RAID 10
USB
AMD® X570 Chipset
- 6 x USB 3.2 Gen 1 (SuperSpeed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB 3.2 Gen 1 connectors)
- 6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB 2.0 connectors)
AMD® Processor
- 2 x USB 3.2 Gen 2 (3rd Gen AMD Ryzen™) or USB 3.2 Gen1 (2nd Gen AMD Ryzen™/ Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics) ports (1x Type-A & 1x Type-C) on the back panel
- 2 x USB 3.2 Gen1 (SuperSpeed USB) Type-A ports on the back panel
Audio
Realtek® ALC1220 Codec
- 7.1-Channel High Definition Audio
- Supports Optical S/PDIF output
LAN
- 1 x Realtek® 8111H Gigabit LAN Controller
Internal connectors
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 1 x 4-pin ATX 12V power connector
- 6 x SATA 6Gb/s connectors
- 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
- 2 x USB 3.2 Gen1 connectors (supports additional 4 USB 3.2 Gen1 ports)
- 1 x 4-pin CPU fan connector
- 1 x 4-pin water-pump connector
- 4 x 4-pin system fan connectors
- 1 x Front panel audio connector
- 2 x System panel connectors
- 1 x TPM module connector
- 1 x Serial port connector
- 1 x Clear CMOS jumper
- 1 x Chassis Intrusion connector
- 2 x 4-pin RGB LED connectors
- 2 x 3-pin RAINBOW LED connectors
- 4 x EZ Debug LEDs
Back panel ports
- Keyboard / Mouse
- USB 3.2 Gen1 Type-A
- LAN Port
- HD Audio Connectors
- Flash BIOS Button
- USB 2.0 Ports
- HDMI Port
- USB 3.2 Gen2 Ports (Type-A + C)
- USB 3.2 Gen1 Type-A Ports
- Optical S/PDIF out

Dimensions
- 12 in. x 9.6 in. (30.4 cm x 24.3 cm)
- ATX Form Factor
Mounting
9 mounting holes
Operating System
- Support for Windows® 10 64-bit
