Processor

Supports Intel^® 10^th Gen processors for LGA 1200 socket

Chipset

Intel^® H410 Chipset

Memory

• 2x DDR4 memory slots, support up to 64GB
• Intel^® Core™ i7/ i9
  • Supports up to DDR4 2933 MHz
• Intel^® Core™ i5 and below
  • Supports up to DDR4 2666 MHz
• Supports Dual-Channel mode
• Supports non-ECC, un-buffered memory
• Supports Intel^® Extreme Memory Profile (XMP)

Expansion Slot

• 1x PCIe 3.0 x16 slot (From CPU)

Onboard Graphics

• 1x HDMI port, supports a maximum resolution of 4096×2160 @30Hz
• 1x DisplayPort, supports a maximum resolution of 4096×2304 @60Hz

Storage

Intel^® H410 Chipset

• 4x SATA 6Gb/s ports
• 1x M.2 slot (Key M)
  • Supports PCIe 3.0 x4
  • Supports SATA 6Gb/s
  • Supports 2280 storage devices

  <!–

  1. Please refer www.msi.com for more information on compatible memory.

  –>

USB

Audio

Realtek^® ALC1200 Codec

• 7.1-Channel High Definition Audio
• Supports S/PDIF output

LAN

• 1x Intel^® 1219V Gigabit LAN Controller

Wireless LAN &
Bluetooth^®

Intel^® 3168NGW

• The Wireless module is pre-installed in the M.2 (Key-E slot
• Supports 802.11 a/ b/ g/ n/ ac
• Supports Bluetooth^® 4.2

Internal connectors

• 1x 24-pin ATX main power connector
• 1x 8-pin ATX 12V power connector
• 4x SATA 6Gb/s connectors
• 1x M.2 slot (M-Key)
• 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports)
• 1x USB 2.0 connector (supports additional 2 USB 2.0 ports)
• 1x 4-pin CPU fan connector
• 1x 4-pin water-pump fan connector
• 1x 4-pin system fan connector
• 1x Front panel audio connector
• 1x System panel connector
• 1x 4-pin RGB LED connector
• 1x 3-pin RAINBOW LED connector
• 1x Chassis Intrusion connector

Back panel ports

Dimensions

• Mini-ITX Form Factor
• 6.7 in. x 6.7 in. (17.0 cm x 17.0 cm)

Mounting

4 mounting holes

Operating System

Support for Windows^® 10 64-bit

Box content
